Features

• Precision positioning of rotary table, (4 x 90°) by optical projection-type reading equipment

• Power operated tool clamping (MUN)

• Cross and Longitudinal slide surface covered with plastic

• Guideways of bed and slide are lined with hardened steel strip inserts

• Speeds of faceplate and spindle may be either in conjunction or independent of each other

• Central lubrication of guideways

• Sliding telescopic guards (in selected areas)

• Thread cutting attachment for 18 metric and 18 Whitworth threads

Standard Equipment

• Built-in Faceplate

• Anchoring Material

• Set of Service Tools

• Tailstock

Specifications

• Spindle Diameter: 3.93"

• Spindle Taper: ISO 50

• Out Travel: 35.43"

• Max. Diameter of Face Turning: 35.43"

• Speed Range (23): 7.1 - 1120 RPM

• Faceplate Speed (16): 7.1 - 224 RPM

• Faceplate Diameter: 23.62"

• Clamping Surface: 49.21" x 49.21"
  Travels:

• X-Axis: 62.99"

• Z-Axis: 49.21"

• Y-Axis: 44.09"

• Voltage: 600v

• Max. Table Load: 6614 LBS

Feeds (Cross, Longitudinal, Vertical, and Spindle)

• Number (Per Revolution): 32

• Range (Per Revolution): 0.0008" - 0.4724"

• Number (Per Minute): 18

• Range (Per Minute): 0.708" - 35.43"

• Rapid Traverse (Per Minute): 110.24"

General

• Main Drive: 15 HP

• Boring Bar Support Drive: 0.55 KW, 0.75 HP

• Digital Read Out

• Overall Dimension: 234" x 118" x 118"

• Floor Space (LxW): 264" x 118"

• Overall Weight: 30,865 LBS

• Excellent Condition

• ST: 557
